BVOH

Water-soluble supports

The BVOH filament from Fiberlogy is a butene-diol vinyl alcohol copolymer. It can be used to print perfect prototypes, complex structures and movable mechanisms. It particularly comes in handy where traditional supports could be difficult to remove or would not be sufficient to obtain a satisfactory final print result. With BVOH, printing highly complex 3D objects is extremely easy.

Supports created using BVOH filament are very easy to remove. After printing a 3D model, simply place it in warm water and the support filament will dissolve completely. This will result in the actual model being of noticeably better quality than in the case of supports which have to be broken out.

The BVOH filament can be used with printers with a double extruder. It is characterized by high adhesion to various types of materials. It can be combined with popular materials such as PLA, ABS, PET-G, ASA, elastic filaments (e.g. TPU), etc.

The filament should be stored in a dry place, e.g. in a sealed bag, in order to avoid wetting of the material and the resulting deterioration of its properties.

APPLICATION IN 3D PRINTING:

  • PROTOTYPES: functional prototypes, small-size models, models with empty spaces
  • DECORATIONS: complex structures, ornaments with numerous details, vases, jewellery
  • MECHANISMS: moving elements, mechanisms printed as a whole
BVOH
Diameter Net weight Colors
1.75 mm 0.5 kg
MSDS TDS Ask for a product
Expand the description
Find a store

BVOH properties:

  • soluble in warm water
  • high adhesion to PLA, ABS, ASA, PET-G, TPU and other filaments
  • environmentally friendly – can be disposed of in your home sewage system

How to print BVOH?

The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to choose the appropriate settings for a specific printer and printing conditions.



Nozzle Temperature 190-220°C
Bed Temperature 50-70°C
Closed chamber not required
Fan 75-100%
Flowrate 95-105%
Printing Speed < 35 mm/s
Surface glass, masking tape
Retraction (direct) 2-3 mm
Retraction (bowden) 4-6 mm
Retraction Speed 20-45 mm/s
Drying conditions 50°C / 4h
Notes Protect from moisture (Store filament in tightly sealed containers when not in use)



Diameter Diameter tol Oval tol Printing temp Table temp
1.75 mm +/- 0.02 mm + 0.01 mm 190-220°C 50-70°C

Colors: BVOH

Fiberlogy BVOH Natural

Natural
